8 Settings via the MICT
Rev. 03/2019 73
The status bar provides you with the following information (from left to right):
– Status display
Indicates whether a connection is established with the device:
– Green: Connection established
– Red: The connection was interrupted and is being restored
– Gray: The connection is not established and is not being restored
– Indication of the interface being used for the connection to the device
– Indication of the device ID
– Indication of the access level of the user in the MICT
– Indication of the operating level for the MIC5 if access control has been activated and the
user has logged on with a PIN.
– Indication of the MICT program version
8.5 Menu Bar and Toolbar
The following functions are available to you via the symbols on the toolbar and the entries in the
menu bar:
Symbol Menu Function
File -> New
Creates a new configuration.
File -> Open
Opens an existing configuration.
File -> Save /
File -> Save As
Saves the current configuration.
File -> Recent Documents
The last five configuration files used are offered
for selection.
File -> Close
Closes the current configuration.
File -> Open trace
Opens a runtime data record (trace file). Refer to
the section Runtime Data on page 114.
File -> Open pickup trace
Opens a saved record of pickup signals (putrace
file). Refer to the section Pickup Trace on
page 78.
File -> Change Access Level
Changes the MICT access level for accessing the
configuration data and functions.
