4 Product Description
30 Rev. 03/2019
4.1.9 LEDs and Connections
LEDs on the MIC5
Labeling Function
Status LED flashes green when the device is running with no errors. If an error
occurs, the LED is red, for a warning it is yellow.
Firing LED lights up when the ignition is active (exception: during the self test).
Pickup 1 to 3 Flashing LEDs indicate activity of the pickups.
GPO LED is on when the GPO is activated.
Connections and Functions under the Service Cover
