8 Settings via the MICT
112 Rev. 03/2019
CAN
Clicking on the CAN checkbox enables or disables the CAN interface on the device.
– ALL-IN-ONE (J1939)/J1939/CANopen
Select the desired protocol, depending on whether you want to set the communication for
the ALL-IN-ONE or for another device. For example, for a connection to the PowerView3,
select CANopen.
– J1939 Settings
The J1939 source address can be assigned between 0 and 253. Note that IDs cannot be
assigned more than once. The Address Filter can be used to set that broadcast PGNs are only
accepted from one or two specific source addresses you have entered. If the filter is
deactivated, the broadcast PGNs are accepted from all source addresses.
– CANopen Settings
The CANopen node ID can be assigned between 1 and 127. Note that IDs cannot be assigned
more than once.
– Baudrate
Select the desired data transfer rate from the list. The baud rate can be defined between
50 kbit/s and 1 Mbit/s, the recommended value being 250 kbit/s.
RS485
Clicking on the field RS485 enables or disables the Modbus interface on the device.
– Baudrate
Select the desired data transfer rate from the list. The Modbus baud rate can be defined
between 9,600 bit/s and 115,200 bit/s, the recommended value being 19,200 bit/s.
– Parity
Define if a parity bit is used and if the parity is to be even or odd.
– Stopbits
Determine if one or two stop bits are to be sent. Two stop bits can only be sent if no parity
has been selected.
– Modbus Address
The Modbus address can be assigned between 1 and 247. Note that IDs cannot be assigned
more than once.
– Mode
Define if the data are transferred in the ASCII or RTU mode.
Setting the transfer rate
Please note that all devices connected with a bus must be set to the same
transfer rate.
