6 Wiring of the Device
38
Rev. 03/2019
Pin designation
Connection no. on connector strip
35-pole connector
Pickup 3
Power
9
–
Signal
10
–
GND
11
–
Shield
12
–
CAN Display
Hi
CAN
1
–
Com
2 –
Lo
3
–
Shield
4 –
CAN
Hi
5
L
Com
6 M
Lo
7
N
Shield
8 P
Go/NoGo +
Binary
Output
1
R
Go/NoGo –
2
S
GPO +
3
T
GPO –
4
U
ASO +
5
V
ASO –
6
W
ASO Shield
7
X
Timing U in +
Analog/
Binary
Input
1 –
Analog GND
2
d
Analog PWR
3 e
Timing I in –
4
f
Timing I in+
5 g
Analog Shield
6
h
Start/Stop +
7 j
Schedule A/B +
8
k
GPI1 +
9 l
Binary Com
10
m
Binary Shield
11 –
37
39
Table of Contents
Default Chapter
3
Table of Contents
3
1 General Information
8
What Is the Purpose of this Operating Manual
8
Who Is this Operating Manual Targeted to
8
Which Symbols Are Used in the Operating Manual
8
Which Abbreviations/Acronyms Are Used in the Operating Manual
9
2 Safety Instructions
11
General Safety Instructions
11
Electrostatic Discharge Hazards
12
Information on Electric Isolation
13
Special Safety Instructions for the Device
14
Proper Disposal
16
3 Intended Use
17
Functional Description
17
Applications
17
4 Product Description
18
Technical Data
18
Certifications
18
Mechanical Data
19
Warning Notices on the Device
20
Product Identification - Labeling on the Device
21
Electrical Data
21
Interfaces
25
Requirements for External Equipment
26
Overview Drawings
27
Leds and Connections
30
5 Installation Instructions
32
Unpacking
32
Installation of the Ignition Controller
32
Installation of the Vibration Dampers
33
Installation of the Ground Strap
34
Determine the Installation Location of the Pickup
35
6 Wiring of the Device
36
Input and Output Wiring on the Controller
36
Input Wiring
37
Input Wiring - Power Supply
39
Input Wiring - Pickups
41
Input Wiring - Timing and Safety Devices
43
Output Wiring - Binary Outputs (Go/Nogo, GPO, ASO)
46
Wiring - Powerview3
47
Output Wiring - CAN Bus Interface
49
Output Wiring - RS485 Interface
51
Ignition Coil Wiring
53
Ignition Coil Wiring for a 35-Pole Connector
54
Ignition Coil Wiring 17-Pole and 14-Pole Connector
55
Straight Order Wiring of the Ignition Outputs
56
Straight Order Wiring of the Ignition Outputs - Overview
57
7 Functions
59
Pickup Sensitivity
59
Monitoring of Pickup Signals
59
Go/Nogo
59
Ignition Timing Adjustment
60
Manual Timing Correction
62
Analog Inputs
62
Cylinder-To-Cylinder Alignment
64
Speed Curve
64
Ignition Timing Correction
64
Firing Angles
64
HV-Power Supply Error Monitoring
64
Output Monitoring
65
Schedules A/B
65
Alarms
65
GPO: General Purpose Output
66
ASO: Auxiliary Synchronization Output
66
Ignition Energy
68
Access Control
68
8 Settings Via the MICT
70
MICT System Requirements
70
MICT Installation
70
Access Levels in the MICT
71
Configuration Pages (Overview)
72
Menu Bar and Toolbar
73
Online Update Settings
76
Self Test
77
Pickup Trace
78
Access Control for MIC5
81
Enable/Disable Access Control
81
Login/Logout
82
Changing the PIN
82
Reset All Pins
82
Working with Configurations
83
Create, Open, Save
84
Upload, Download
85
Compatibility Information
86
Configuration
87
Engine - Parameters
88
Engine - Cylinder Names
91
Engine - Ignition Outputs
92
Engine - Ignition Coils
94
Engine - Pickups
96
Timing - Analog Inputs
100
Timing - Schedule A/B - General
102
Timing - Schedule A/B - Energy
104
Timing - Miscellaneous
105
Inputs/Outputs - Alarms
106
Inputs/Outputs - ASO1 (Auxiliary Synchronization Output)
108
Inputs/Outputs - Inputs
110
Miscellaneous - Communication
111
Miscellaneous - Information
113
Runtime Data
114
Runtime Data - Overview
115
Runtime Data - Timing
118
Runtime Data - Ignition
119
Runtime Data - Bank a and B
120
Runtime Data - States
122
Runtime Data - Message Log
128
Information
130
Warnings
133
Alarms
134
Failure
134
Runtime Data - Diagnostics
138
Runtime Data - Temperatures
140
Runtime Data - Information
141
Log
142
Runtime Adjustments
143
Runtime Adjustments - Reset
144
Runtime Adjustments - Timing
145
Runtime Adjustments - Energy
146
Runtime Adjustments - Secondary Voltage Estimation Calibration
147
Runtime Adjustments - Secondary Short Calibration
148
Cylinder Individual Offsets
149
Schedule Curve
151
Schedule Curve - Simulation
151
Schedule Curve - Runtime Values
153
Coils
154
General
155
Min. Energy Limit Curve
157
9 Operation
158
Start-Up
158
Shutdown
158
Firmware Update
159
10 Errors
163
Possible Faults
163
Causes of Faults
163
Overspeed
163
Output Error Detection
163
Misfire Detection (Primary)
163
Pickup Input Errors
164
Acknowledging Faults
164
Troubleshooting
165
Running a Self Test
165
Customer Service Information
165
Returning Equipment for Repair/Inspection
165
Instructions for Packaging the Equipment
166
Maintenance
167
Index
168
