8 Settings via the MICT
Rev. 03/2019 93
– Column: Output
Select the number of the respective output.
– Column: Angle
Enter the firing angle for each output.
Default Application
If you select from the engine database, the data stored for the selected configuration are
displayed. These data can only be changed by personnel with access to the Advanced Service
level.
New Engine Configuration
If you have created a new engine configuration on the configuration page Engine – Parameters
using the corresponding button, first the number of outputs corresponding to the number of
cylinders are distributed to the output bank A and output bank B. Selecting the number of
outputs enables access to the fields for the configuration of the outputs. We recommend that
you distribute the number of outputs evenly among the output banks and allocate the larger
number to the A output bank if the number is uneven.
By default, the ignition outputs are distributed so that cylinder 1 of the firing order is always
allocated to output bank A with a firing angle of 0°. The further distribution is implemented by
alternating between output bank A and B. The firing angle for each output results from the
addition of the firing interval to the respective previous output.
Operational safety!
Never connect more than one output to each ignition coil, as the output
boards can otherwise be damaged!
The allocation of outputs on the output banks to contacts of the output connector of the device
and the cylinders is determined by the wiring. The user must take the wiring into account during
the configuration; it cannot be checked by the software.
Interval between two ignitions
The interval between two ignitions on an output board must be min. 2.8 ms.
During the check, the configured overspeed is used in the calculation.
To Next Page
