9 Visualization
Maschinenfabrik Reinhausen GmbH 2020 1856385142/08 EN ETOS
®
ED
Response to active power P
max
being exceeded
If the measured active power P
meas
exceeds the set parameter P
max
, the value
U
max
is adopted as the desired value.
U
ref
= U
max
Response to value falling below active power P
min
If the measured active power P
meas
falls below the set parameter P
min
, the
value U
min
is adopted as the desired value.
U
ref
= U
min
Response to a measured active power P
meas
=0MW:
If the measured active power P
meas
=0, the set parameter U
0
is adopted.
U
ref
= U
0
Linear dependency with negative active power:
If the measured active power P
min
≤P
meas
≤0, the desired value is calculated
using the following equation:
U
ref
=
U
0
- U
min
0 - P
min
×P
meas
+ U
0
Linear dependency with positive active power:
If the measured active power 0≤P
meas
≤P
max
, the desired value is calculated
using the following equation:
U
ref
=
U
max
- U
0
P
max
×P
meas
+ U
0
To activate the active power-dependent adjustment of the desired voltage
value, you need to set the following parameters:
Activating TDSC
The TDSC function is only active when the device can calculate the active
power (correct current measurement and voltage measurement) and the re-
quired parameters are set. If this isn't done, the voltage is regulated to the
set desired value 1/2/3 [►Section 9.16.1.2, Page 177]. You can activate or
deactivate the power-dependent adjustment of the desired voltage value as
follows:
▪ Parameter
▪ Digital inputs TDSC on and TDSC off (optional)
▪ Control system command (optional)
