If you activate TDSC, the line drop compensation (R&X compensation or Z
compensation) function is deactivated.
To activate/deactivate TDSC using parameters, proceed as follows:
1. Go to Settings > Parameters > Control > Activate TDSC.
2. Select the option you want.
3. Press the Accept button to save the modified parameter.
TDSC 1/2/3 Umax/Umin
You can use these parameters to set the maximum and minimum desired
value. The maximum or minimum desired value is activated when the mea-
sured active power reaches the set minimum or maximum active power.
1. Go to Settings > Parameters > Control > TDSC Umax/Umin.
2. Enter maximum/minimum desired value.
3. Press the Accept button to save the modified parameter.
TDSC 1/2/3 U0
You can use this parameter to set the desired value which is to be used
when the measured active power is 0.
1. Go to Settings > Parameter > Control > TDSC U0.
2. Enter desired value at active power 0.
3. Press the Accept button to save the modified parameter.
TDSC 1/2/3 Pmax/Pmin
You can use these parameters to set the maximum and minimum active
power value at which the maximum and minimum active power-dependent
desired value is to be used for regulation.
1. Go to Settings > Parameters > Control > TDSC Pmax/Pmin.
2. Enter active power for maximum/minimum desired value.
3. Press the Accept button to save the modified parameter.
9.16.1.8 Desired value setting via BCD
With the desired value setting via BCD, you can variably adjust the desired
value for the automatic voltage regulation via digital inputs by means of BCD
coding.
Depending on variant, desired value setting via BCD is always active or you
can activate it by creating a signal at the BCD desired value input.
