7 Functions and settings
Maschinenfabrik Reinhausen 2014 1233550953/00 EN TAPCON® 230 pro
To display data for parallel operation, proceed as follows:
► > Info > Press until the desired display appears.
ð Parallel operation.
Displaying data on CAN bus
The CAN bus data of the connected devices is shown in this display.
Figure 68: CAN bus data
1 CAN bus address of device 4 Reactive current in %
2 Actual voltage (U
Act
) in V 5 Tap position
3 Active current in %
To display information about data on the CAN bus, proceed as follows:
► > Info > Press until the desired display appears.
ð Data on CAN bus.
Peak memory
This display indicates whether the parameter sets are all correctly stored af-
ter restarting the device or after transferring a parameter set. The minimum
and maximum voltage measured since the last reset and the minimum and
maximum on-load tap-changer tap positions are shown here. All values re-
corded are stored with a time and date.
The minimum and maximum values continue to be stored in an internal
fixed value memory even in the event of power failure.
7.13.8
7.13.9
