6 Commissioning
Maschinenfabrik Reinhausen 2014 493550953/00 EN TAPCON® 230 pro
Setting line drop compensation (optional)
If you need line drop compensation, you must set all important parameters
for this:
1. Select LDC compensation method [► 86].
2. Set line data for the ohmic voltage drop Ur [► 88].
3. Set line data for the inductive voltage drop Ux [► 89].
Setting parallel operation (optional)
If you need parallel operation, you must set all important parameters for this:
1. Set parallel operation method to circulating reactive current method
[► 99].
2. Assign CAN bus address [► 98].
3. Set circulating reactive current sensitivity [► 100].
4. Set circulating reactive current blocking [► 100].
Setting tap position capture via analog input (optional)
If you want to capture the tap position via the analog input, you must set the
parameters required for this:
► Capture tap positions via analog input (PIO card terminal strip X7)
[► 107].
All parameters relevant to commissioning are entered. Continue with the
function tests.
Setting the desired voltage level remotely
If you would like to set the desired voltage level remotely, you must config-
ure the necessary parameters:
► Activate "Set the desired voltage level remotely" and set the relevant pa-
rameters [► 109].
Function tests
Before switching from manual mode to auto mode, Maschinenfabrik Rein-
hausen recommends carrying out function tests. These function tests are de-
scribed in the following sections. Note the following points for all function
tests:
▪ You must ensure that the REMOTE mode is disabled before you can
control the on-load tap-changer manually in manual mode.
▪ You can only activate the on-load tap-changer manually in manual
mode using the and keys.
6.3
