3 Product description
Maschinenfabrik Reinhausen 2014 173550953/00 EN TAPCON® 230 pro
▪ Digital inputs and outputs can be individually programmed on-site by the
user
▪ Additional indicators using LEDs outside the display for freely selectable
functions
▪ Display of all measured values such as voltage, current, active power,
apparent power or reactive power, power factor (cos φ)
▪ Selection of 3 different desired values
▪ When ordering you can choose between tap position capture:
– using analog signal 4…20 mA
– using analog signal via resistor contact series
– using digital signal via BCD code
▪ Additional digital inputs and outputs which can be freely parameterized
by the customer
▪ Parallel operation of up to 16 transformers in 2 groups using the follow-
ing methods:
– Master/Follower
– Circulating reactive current minimization
Operating modes
The device can be operated in the following operating modes:
Auto mode (AUTO)
In auto mode, the voltage is automatically controlled in accordance with the
set parameters. You cannot change further device settings in auto mode.
There is no active management by a higher level control system in this oper-
ating mode.
Manual mode (MANUAL)
In manual mode, there is no automatic control. The motor-drive unit can be
controlled via the device's operating panel. You can change the device set-
tings.
Local mode (LOCAL)
There is no active management by a superordinate control system in this op-
erating mode.
Remote mode (REMOTE)
In remote mode, you can perform commands using an external control level.
In this case, manual operation of the , , and keys is disa-
bled.
3.4
