5 Mounting
Maschinenfabrik Reinhausen 201430 3550953/00 ENTAPCON® 230 pro
Mounting
This chapter describes how to correctly mount and connect the device. Note
the connection diagrams provided.
WARNING
Electric shock
Risk of fatal injury due to electrical voltage.
► De-energize the device and system peripherals and lock them to pre-
vent them from being switched back on.
► Do so by short-circuiting the current transformer; do not idle the current
transformer.
NOTICE
Electrostatic discharge
Damage to the device due to electrostatic discharge.
► Take precautionary measures to prevent the build-up of electrostatic
charges on work surfaces and personnel.
Preparation
The following tools are needed for mounting:
▪ Provided 3mm Allen key (included in delivery)
▪ Small screwdriver for connecting the signal lines and supply lines
Other tools may be needed depending on installation location.
Mounting device
You can mount the device in the following installation versions:
▪ Flush panel mounting
▪ Wall mounting
▪ Wall mounting with mounting brackets
▪ Rail mounting (optional)
5
5.1
5.2
