3 Product description
Maschinenfabrik Reinhausen 2014 193550953/00 EN TAPCON® 230 pro
Hardware
Figure 6: Hardware
1 Operating panel with display
and LEDs
3 Door
2 Door lock 4 Metric cable glands
3.5
