5 Mounting
Maschinenfabrik Reinhausen 2014 453550953/00 EN TAPCON® 230 pro
Wiring device
To obtain a better overview when connecting cables, only use as many
leads as necessary.
To wire the device, proceed as follows:
ü Use only the specified cables for wiring. Note the cable recommendation
[► 38].
ü Wire the lines to the system periphery [► 44].
1. Remove 4 hexagon socket screws from cover plate and take off cover
plate.
2. Disconnect the connectors required.
3. Remove 4 hexagon socket screws from the cable gland plate and take
off the cable gland plate.
4. Remove dummy plug from required cable glands in order to guide ca-
bles through.
Unnecessary cable glands must be sealed with dummy plugs to guarantee
the IP54 protection category.
5. Strip insulation from lines and leads.
6. Crimp stranded wires with core cable ends.
7. Guide cables through the cable gland
8. Guide leads into corresponding connector terminals.
9. Fasten screws for the corresponding terminals using a screwdriver.
10. Guide the cable gland plate into the device opening provided for this
purpose.
11. Plug connectors into the correct slots.
12. Secure cable gland plate to device housing with 4 hexagon socket
screws.
Checking functional reliability
To ensure that the device is wired correctly, check its functional reliability.
NOTICE
Damage to device and system periphery
An incorrectly connected device can lead to damages in the device and sys-
tem periphery.
► Check the entire configuration before commissioning.
► Prior to commissioning, be sure to check the actual voltage and operat-
ing voltage.
5.3.6
5.3.7
