12 Technical data
Maschinenfabrik Reinhausen 2014142 3550953/00 ENTAPCON® 230 pro
IEC 61000-4-4 Fast transients (burst) 6.5 kV
IEC 61000-4-5 Surge transient immunity 2 kV (out-
er conductor/outer conductor), 4 kV
(outer conductor/ground)
IEC 61000-4-6 HF interference immunity (lines)
10 V, 150 kHz...80 MHz
IEC 61000-4-8 Power frequency magnetic field im-
munity 1000 A/m
IEC 61000-6-2 Immunity requirements for industri-
al environments
IEC 61000-6-4 Emission standard for industrial en-
vironments
Table 51: Electromagnetic compatibility
Environmental durability tests
DIN EN 60529 Determination of protection class
for "protection against contact, in-
gress of foreign objects and water
for electrical equipment" Level IP54
IEC 60068-2-1 Dry cold - 25 °C / 16 hours
IEC 60068-2-2 Dry heat + 70 °C / 16 hours
IEC 60068-2-3 Constant moist heat + 40 °C /
93% / 21 days
IEC 60068-2-30 Cyclic moist heat (12 + 12 hours)
+ 55 °C / 93% and + 25 °C / 95% /
6 cycles
Table 52: Environmental durability tests
Mechanical stability
IEC 60068-2-31 Drop and topple, unpacked 100
mm fall height
IEC 60068-2-32 Free fall, unpacked 250 mm fall
height
IEC 255-21-1 Class 1 Bounce test
IEC 255-21-2 Class 1 Shock and bump test
IEC 255-21-3 Class 1 Seismic test
Table 53: Mechanical stability
