Voltage Chart
Incoming at Switch
(L1,L2,L3)
____________
Transformed Power
(Pins 23&24)
____________
Mechanical Installation: PHASE II
Electricity is required.
Slightly loosen gantry bolts
– Loosen both sides of the X-axis (moving gantry only).
Hard Home
– If machine will not find limits, then see Help Docs.
Verify Resolutions
– See Help Docs for more information on how to check resolution
Verify Table Parameters
– Jog the full distance in X-, Y-, & Z-axes. Make sure that the gantry & head
do not make physical contact with the end stops.
Verify the cutting head is parallel to the table
.
Square Table
– Use a pen taped to the side of the head to make 4 points to verify the square of the
gantry. The bigger the perfect rectangle or square, the more accurate.
Tighten Gantry Bolts
– Tighten both sides of the X-axis (moving gantry only).
Suite4 Machine Software Installation
Reboot Machine – Check for red letter errors.
Capture NVRAM – Check the factory Flash settings before making any modifications. Save to
Computer and Tech computers.
Check Init and Firmware Version – Type v & press Enter. Capture the screen or write down the
information. Make updates if necessary.
Interface Board ____________ Init File Version Loader ____________
Controller Board Revision ____________ Init File Version STD ____________
Firmware Version (MCIF) ____________ MD4 Version ____________
Help Files – Manuals & Help Docs JobNameServer – Confirm operations.
JobReporter – Confirm operations. JobEditor – Confirm operations.
ConnectionManager – Confirm operations. JobConsole – Check if Auto Preview
works & if Job Monitor is on.
Routers * Lasers * Plasma * WaterJets * Knife Cutters
www.MultiCam.com
To Next Page
