Step 5: Performs confirm print.
 Press + or – to select "PF3: Confirm Print".
 Press Enter.
 "Feed Length: 250 mm" is displayed.
 Press ENTER.
 "Printing" is displayed.
 Start Confirmation adjustment printing.
 When the Confirm Print is complete, the printer enters Normal.
 After the confirmation adjustment printing, cut the media.
Refer to “Cutting media on page91
”
Step 6: Measure the distance between the two pluses in the confirmation adjustment print
using a ruler. Then, confirm that the distance matches the feeding length when
printing.
 If the distance does not match the feeding length, follow the procedure from Step
1 to Step 5 and readjust.
 If the distance matches the feeding length, proceed to step 7.
Step 7: Perform Micro adjustment printing.
 Display the Media feed compensation menu in the same way as in step 1.
 Press + or – to select "PF4:Micro Print".
 Press Enter.
 "Printing" is displayed.
 Start Micro adjustment printing.
Note
 The length of media that is fed for the initial adjustment print is normally set to
250 mm.
 If you increase the feeding length, the accuracy of the media feed
compensation improves.
To change the feeding length, press the [+] or [-] key and change the set value.
N° Description
1 Feed length
2 Media feeding direction
