VJ-1628X OPERATION MANUAL Before using
3.7 Print quality adjustment 117
3.7.1 Standard print quality adjustment
Adjusts only the print mode in the user type setting which is currently set.
This menu consists of the following menus.
Follow the procedure below to perform adjustment.
1. Print out the confirmation pattern and check the degree of misalignment.
3.7.1.1 Standard confirmation pattern
2. Perform rough adjustment when the degree of misalignment is big.
3.7.1.2 Standard rough adjustment pattern
Perform micro adjustment when the degree of misalignment is small.
3.7.1.3 Standard micro adjustment pattern
• Perform rough adjustment first when the degree of misalignment is difficult to determine.
3. Print out the confirmation pattern again and check if the printer has been adjusted properly.
3.7.1.1 Standard confirmation pattern
4. If it has not been adjusted yet, return to step 2.
• Perform micro adjustment if the printer is not fully adjusted after rough adjustment.
Menu name Description Reference
Standard confirmation
pattern
Print out the confirmation pattern and check the
degree of misalignment.
3.7.1.1 Standard confirmation
pattern
Standard rough adjustment
pattern
Perform this when the degree of misalignment is big.
3.7.1.2 Standard rough
adjustment pattern
Standard micro adjustment
pattern
Perform this when the degree of misalignment is
small.
3.7.1.3 Standard micro
adjustment pattern
