VJ-1628X OPERATION MANUAL Handling the printer
4.4 Operating from Operation panel 181
4.4.4 Cutting media manually
This section explains how to cut the roll media manually.
• Right after printing, Media guide becomes very hot.
Allow Media guide to cool down before the next operation.
Follow the procedure below to cut the roll media.
1. Verify the following regarding the operational condition of the printer.
• Printing or other operations are not in progress.
• Operation panel display is Normal.
2. To change the position to cut the roll media, refer to
4.4.1 Feeding media and advance the roll
media to the desired cut position.
3. Open Front cover.
No. Name
1 Front cover
To Next Page
