232 5.1 Setup menu
5.1.12.1 Layer Multi Strike menu
You can set the number of multi strikes for each layer when performing layer printing.
• When setting W 7Color, “3: Mt” is not displayed.
• Layer printing depends on the function of the RIP software supported.
Ink film thickness
Ink film thickness changes depending on the set number of multi strikes to be layered.
• The more number of strikes, the thicker the ink film becomes.Note that depending on the media
being used, the print head and ink film may come in contact and break the print head.
• Ink film thickness differs by print mode.
Setup item Setting Description
Layer Multi Strike 1: Co Shifts to the Multi strike settings for Cyan (C), Magenta (M),
Yellow (Y), Black (K), Light Cyan (Lc) and Light Magenta
(Lm).
5.1.12.1.1 Color Layer menu
2: Wh Shifts to the Multi strike settings for White (Wh) ink.
5.1.12.1.2 White Layer menu
3: Mt Shifts to the Multi strike settings for Metallic (Mt) ink.
5.1.12.1.3 Metallic Layer menu
— • [Enter] key: shifts to the sub menu.
• [Cancel] key: cancels the setting and shifts to the previous
menu.
