Before using VJ-1628X OPERATION MANUAL
72 3.4 Filling ink
3.4.5 Installing High Capacity Ink Pack Adapter (option)
Use the optional High-capacity ink pack adapter to use the 1000ml Ink packs.
Follow the procedure below to install High-capacity ink pack adapter.
1. Check the angle of Ink cartridge slot to see if the insertion angle of Ink cartridge is horizontal.
• If the insertion angle of Ink cartridge is not horizontal, change the angle.
3.4.4 Changing the angle of Ink cartridge slot
2. Turn the printer ON.
• The printer starts the initializing operation.
• After the initial operation is compete, “Start Ink Charge – > E” is displayed on Operation panel.
No. Name
1 Ink cartridge slot
To Next Page
