Before using VJ-1628X OPERATION MANUAL
146 3.7 Print quality adjustment
3.7.2.3 Custom micro adjustment pattern
Perform micro adjustment when the degree of misalignment is small.
This menu consists of the following menus.
3.7.2.3.1 Fine Pattern ALL
Print micro adjustment pattern ALL and register the set values.
1. Display the Custom Adjust Print menu on Operation panel in the same way as Step 2 of
3.7.2.1 Custom confirmation pattern.
2. Press the [+] key or [-] key on Operation panel to select “Adj.9: Fine Ptn. ALL”.
3. Press the [Enter] key on Operation panel.
• “Warming Up Skip ->E” is displayed on Operation panel.
Menu name Description Reference
Custom micro
adjustment
pattern
Fine PatternALL All confirmation patterns (A to F) will be
adjusted.
3.7.2.3.1 Fine Pattern ALL
Fine Pattern A to
F
One of the confirmation patterns (A to F)
will be adjusted.
3.7.2.3.2 Fine Pattern A to F
To Next Page
