Maintenance
VJ-1628X OPERA
TION MANUAL
318
6.5
Disposal of wa
ste fluids
4.
After pouring the waste fluid to the
empty container
, close the waste fluid valve securely
.
5.
W
ipe the opening of W
aste fluid valve with a cloth, etc.
6.
Dispose of the waste fluid as an industrial waste product.
•
Disposal of waste fluids is completed.
No.
Name
1
W
aste fluid valve
1
317
319
