6-20 Operation
To setup the heater tooling in Fluidmove:
WARNING! The heater may be hot. Avoid touching heater surfaces or burn injury may occur.
1. In the Fluidmove Main Window, click on Run a Program .
2. In the Production Window (
Figure 6-15), click on Setup and in the list box select Setup
Heater 2
.
! The Heater Control Window (
Figure 6-16) will open.
Figure 6-15 Fluidmove Production Window
3. In the Heater Control Window (Figure 6-16), locate the loop (channel) for the desired heater.
