4-26 Power-Up and Testing
To test the Safety Interlock effect on the Dispensing Head:
1. In the Main Window, click on the
Jog icon .
2. In the Jog Commands dialog box (
Figure 4-17), verify the Dispenser radio button is selected
and then click on the
Home button.
3. While the dispensing head is moving toward its home position, open the hood.
! The green beacon light should go OFF, the yellow beacon light should come ON, and the
dispensing head should stop moving.
4. Close the dispensing system hood.
! The yellow beacon light should go OFF, the green beacon light should come ON, and the
Dispensing Head should continue moving toward its home position.
To test Dispensing Head movement:
1. In the Jog Commands dialog box (
Figure 4-17), click inside of the target box in three or more
locations.
! The dispensing head should smoothly move to the chosen locations.
2. Click on the slow
and the fast X-and Y-axis jog buttons to move the dispensing head
to the extreme X and Y limits of travel.
! No unusual vibrations should occur during dispensing head motion.
! The dispensing head should move freely about the dispensing chamber.
! The cable cat track should not impede dispensing head motion.
3. Click on the slow
and the fast Z-axis jog buttons to move the dispensing head up and
down.
CAUTION! The downward travel of the dispensing head must not exceed 3.5 inches
(88 mm) or damage to components will occur.
! No unusual vibrations should occur during dispensing head motion.
! Pneumatic and electrical cables should not impede the Z-axis motion or be in danger of
being snagged or cut.
4. Close the Jog Commands dialog box to return to the Main Window.
