Nortel CallPilot - Page 103

Replacing a faulty hard drive 103
4
Install the new hard drive in the drive carrier as described in Pull
the drive carrier out of the chassis, and then place it cage-side-up
on an antistatic surface...
5
Install the drive carrier assembly in the server as described in "To
install the hard drive" (page 107).
—End—
Hard drive description
The server is equipped with two 36 Gbyte wide SCSI hard drives, each one
inch high. The last bay must remain empty to ensure proper system cooling.
CAUTION
The internal SCSI interface in this system supports only
single-ended SCSI devices. Use Nortel authorized drives only.
SCSI drive cabling
The hard drive assembly package includes a standard 68-pin, 68 conductor,
twisted-pair wide (16-bit) SCSI ribbon cable, with terminator. This cable has
three connectors: the first is for the terminator, the second is for the hard
drive, and the third is for connection to the RAID card.
Hard drive configuration
Ensure that the hard drives are configured as follows (for instructions, refer
to the original equipment manufacturer documentation):
•
termination: Set the hard drive on each SCSI bus to provide termination
power to the bus.
•
active termination (Term Enable): disabled on both drives
ATTENTION
If there is a termination enable jumper on the drive, it must NOT be set.
Termination must be provided by a SCSI terminator attached at the end of
the cable.
•
parity checking: enabled on both drives
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
