104 Chapter 9 Replacing media drives
•
all other settings: factory default
RAID and SCSI settings
Location of hard drives
in internal drive bays
(from the top down)
RAID
channel SCSI ID
Hard drive
label in the
RAID software
Drive bay 4
(empty - used for airflow)
Not
applicable
Not
applicable
Not
applicable
Drive bay 5
(Hard drive 1)
00
A0-0
Drive bay 6
(Hard drive 2)
10
A0-1
Drive bay 7
(empty)
Not
applicable
Not
applicable
Not
applicable
Drive bay 8
(empty)
Not
applicable
Not
applicable
Not
applicable
Drive bay 9
(bottom slot)
This slot must remain empty to ensure proper
system cooling.
Filler panels and EMI shields
System EMI integrity and cooling are both protected by drives that are
installed in the bays or by filler panels and EMI shields that cover the bays.
When installing drives, save the panel and shield to reinstall later, in case
you remove the drive and do not reinstall one in the same bay.
