Replacing a faulty hard drive 105
Hard drive installation overview
To remove a hard drive from the server
CAUTION
Use an ESD wrist strap to protect static-sensitive components.
Step Action
1
Prepare the server for hard drive replacement as follows:
a. Shut down the server, and then disconnect the power and
peripheral device cables.
b. Remove the side cover.
c. Remove the upper fan holder foam.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
