106 Chapter 9 Replacing media drives
For instructions, see "Preparing the server for hardware
maintenance" (page 81).
WARNING
Failure to follow the procedures in "Preparing the server
for hardware maintenance" (page 81) can result in
electrical shock or equipment damage.
2
Open the front panel on the server.
3
Remove and save the two screws that secure the drive’s carrier to
the front of the chassis.
4
Pull the drive out slightly—about 1 cm (0.5 in.).
Pulling the drive out creates more space between the front system
fans and the drives inside the server so that you can disconnect
the cables.
5
If required (to provide more space), temporarily remove the front
system fans from their slots in the bottom fan holder foam. (Do not
disconnect the fans’ power cables.)
6
Reach your fingers between the fan holder foam inside the server
and the hard drives, and carefully disconnect the power and signal
cables for both hard drives.
Note: If you are able to disconnect the cables for only the hard
drive you want to remove, that is acceptable. You may find it
easier, however, to disconnect the cables for both hard drives.
7
Pull the drive carrier out of the chassis, and then place it
cage-side-up on an antistatic surface..
CAUTION
Use an ESD wrist strap to protect static-sensitive
components.
8
Remove the new drive from its protective wrapper, and place it on an
antistatic surface.
9
Record the drive model and serial numbers in your equipment log.
