108 Chapter 9 Replacing media drives
3
Connect the hard drive SCSI cable as follows (the end of the cable
with two connectors is the hard drive end):
a. Ensure that a terminator is connected to the last connector at
the hard drive end of the cable.
b. Connect the second connector on the cable to the hard drive.
Place one hand on the front of the hard drive to hold it in place
while you connect the cable with the other hand.
CAUTION
To prevent damage to the connector pins, ensure that
the cable connector aligns correctly with the hard
drive connector before pushing it into place.
c. Route the cable above the CPU through the vacant space at the
top of the server.
d. Connect the other end of the cable as follows:
•
Connect hard drive 1 to channel 0 on the RAID controller.
•
Connect hard drive 2 to channel 1 on the RAID controller.
e. For proper cooling and airflow, neatly fold and secure the excess
signal cable above the CPU. Use a tie wrap or cable clip to
secure the cable.
CAUTION
Ensure that any cables in the proximity of the fans are
kept away from the fans. If a cable is caught in a fan,
the fan will break.
If you need more information, see "SCSI and IDE drive cabling"
(page 101).
4
Connect the hard drive’s power cable.
Note: The connector is keyed so that you cannot connect it
upside down.
5
At the front of the server, slide the drive into the bay until it clicks
into place.
6
Secure the drive carrier to the front of the server with the screws
you removed earlier.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
