Replacing the CD-ROM drive 115
For instructions, see "Preparing the server for hardware
maintenance" (page 81).
WARNING
Failure to follow the procedures in "Preparing the server
for hardware maintenance" (page 81) can result in
electrical shock or equipment damage.
2
Disconnect the faulty drive’s power and signal (IDE) cables.
3
Open the front panel on the server.
4
Remove and save the two screws that secure the CD-ROM drive to
the front of the chassis.
5
Pull the drive out of the chassis, and then place it on an antistatic
surface.
Note: If you plan to leave the bay empty, install a filler panel and
stainless steel EMI shield on the bay.
6
Remove the four screws and two slide rails from the drive.
7
Place the drive in an antistatic protective wrapper.
8
Continue with "To install a replacement CD-ROM drive" (page 115)".
—End—
To install a replacement CD-ROM drive
CAUTION
Use an ESD wrist strap to protect static-sensitive components.
Step Action
1
Remove the new CD-ROM drive from its protective wrapper, and
place it on an antistatic surface.
2
Record the drive model and serial numbers in your equipment log.
3 Set the new CD-ROM drive to IDE Master by changing the jumper
settings at the back of the drive.
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
