Replacing the CPU 149
Heat sink attached to motherboard
CAUTION
Ensure that you do not bend the wings of the heat sink
while removing the clips as this will cause damage to the
heat sink.
5
Remove the heat sink.
6
Remove the microprocessor as shown in "Remove microprocessor
from heat sink" (page 150).
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
