Replacing the CPU 155
b. Spread the sides of the housing slightly, and then lower the
housing over the heat sink.
c. Release the housing to engage the tabs around the edge of the
heat sink’s platform.
d. Apply pressure to the top of the housing and work with the
bottom tabs until the housing snaps into place. When all four
tabs are secured, the housing will not move.
5
Install the processor fan.
For instructions, see "install processor fan" (page 99).
6 Replace the upper fan holder foam.
7
Replace the server’s side cover.
8
Reconnect all peripheral device cables and power cord.
9
Restart the server and ensure that CallPilot starts.
—End—
Nortel CallPilot
703t Server Maintenance and Diagnostics
NN44200-702 01.03 Standard
5.0 3 April 2007
Copyright © 2007, Nortel Networks Nortel Networks Confidential
.
