4-18 Installing the OSP cables
AccessNode 323-3001-210 Issue 1.0
Procedure 4-4 (continued)
Installing the cable bonding clamps
Figure 4-3
Installation of bonding clamp
FW-15123
—continued—
2.0 inches
(5.08 cm)
1.00 inch
(2.54 cm)
Goes between
plastic wrap
and ground
shield
Electrical tape
Assemble
on the
outside
of sheath
0.5 inches
(1.27 cm)
8.0 inches
(20.32 cm)
FW-15123
