3-4 Connecting commercial power
AccessNode 323-3001-210 Issue 1.0
AC power pedestal
For cabinets equipped with the optional attached ac power pedestal, there is a
3.50-inch opening for ac supply and four 2.00-inch openings for miscellaneous
cable entry and grounding cable entry as required.
Table 3-3 shows the conduit openings in the ac power pedestal.
Table 3-3
AC power pedestal conduit openings
Opening size Conduit trade size Function
3.50 inches
(8.89 cm)
2.50 inches
(6.35 cm)
AC entrance - commercial ac feed
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous - dc feed or grounding
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous - dc feed or grounding
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous - dc feed or grounding
2.00 inches
(5.08 cm)
1.25 inches
(3.18 cm)
Miscellaneous - dc feed or grounding
