Cabinet maintenance operations 12-27
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 12-5 (continued)
Adjusting the float voltage
Action
Step Action
1 Set the EQL/FLT switch to the FLT position.
2 The EQL/FLT switch on the rectifier must be in the FLT position when
adjusting the float voltage.
3 Insert the test leads of the digital voltmeter (DVM) into the test points
(negative to negative, positive to positive).
Note:
On the faceplate of the rectifier module are test points labeled outputs
V+ and V- (see Figure 12-4 on page 12-29).
4 Slowly adjust the FLT potentiometer clockwise to raise the float voltage or
counterclockwise to lower the float voltage to the level proscribed by the
battery manufacturer (see Table 12-10 on page 12-26).
5 Continue rectifier replacement procedures with Procedure 12-6 on page
12-28.
—end—
