Adjusting the rectifier and the dc distribution shelf 10-29
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 10-9 (continued)
Adjusting dc distribution shelf low voltage disconnect
Action
Step Action
1 Ensure that the LVD BYP/NORMAL switch is set to the BYP position.
2 Connect the digital voltmeter to the BAT GRD and -48V test points on the front
of the dc distribution shelf.
3 Monitor the voltage at the test points to verify the LVD threshold.
4 Slowly adjust the TST ADJ potentiometer counterclockwise until one of the
three events shown in Table 10-13 occurs.
5 Continue to adjust the TST ADJ potentiometer clockwise until the voltage
reading reaches -43.0 ± 0.2 V dc.
6 Slowly turn the LVD potentiometer counterclockwise until the LVD LED
extinguishes.
7 Slowly turn the LVD potentiometer clockwise until the LVD LED illuminates.
8 Go to step 11.
9 Using the TST ADJ potentiometer, set the voltage reading to -43.0 ± 0.2 V dc.
10 Slowly turn the LVD potentiometer clockwise until the LVD LED illuminates.
11 Continue the dc distribution shelf adjustments using Procedure 10-10 on
page 10-30.
—end—
Table 10-13
LVD LED indications
If the event that happens while you are
adjusting the TST ADJ potentiometer is Then perform these steps
The LVD LED illuminates before reaching
-43.0 ± 0.2 V dc
go to step 5.
The LVD LED does NOT illuminate before
reaching -43.0 ± 0.2 V dc
go to step 9.
The LVD LED illuminates at -43.0 ± 0.2 V dc go to Procedure 10-10.
