13-34 Cabinet and equipment wiring and cabling
AccessNode 323-3001-210 Issue 1.0
Access bandwidth manager shelf wiring and cabling
The ABM shelf connections are accessed at the side interconnect left (SIL)
connector panel mounted on the left side of the shelf (see Figure 13-22 on page
13-35). The side interconnect right (SIR) connector panel is mounted on the
right side of the shelf (see Figure 13-31 on page 13-46).
SIL card connectors and wiring
The SIL connector wiring information is included in this section. Plugs and
connectors are provided for connections to the BIP, the BBP, the dc distribution
shelf, and the local craft access panel (LCAP).
The SIL connectors provide both in-bay connections and connections for
external use. The connectors for internal bay connection are:
• J01 - copper-distribution shelf metallic test access (CDS MTA), 25-Pin
• J02 - Local craft access panel cable 2 (LCAP 2), 25-Pin
• J03 - Local craft access panel cable 1 (LCAP 1), 44-Pin
• J05 - Cooling unit interface (CU IF), 9-Pin
• J13 - Breaker interface panel control (BIP Ctl), 44-Pin
The connectors for external connections are:
• J04 - Orderwire extension, 25-Pin
• J06 - Serial telemetry, 25-Pin
• J07 - Operations controller (OPC) RS232 to VT100, 9-Pin
• J08 - Modem RS232 DTE, 9-Pin
• J09 - Cont net Out, 9-Pin
• J10 - Cont net In, 9-Pin
• J11 - Parallel telemetry, 44-Pin
• J12 - External sync IF, 25-Pin
