Cabinet maintenance operations 12-47

AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0

Procedure 12-14 (continued)

Replacing a fan unit in the air induction roof

Figure 12-12

Interior view of the fans in an air induction roof (looking up from inside cabinet)

FW-11327

—end—

Exhaust Side

Intake Side

AC Compartment

SAI Compartment

Intake Fans (5)

Exhaust Fans (6)

FW-11327

Latches

(Open hinged,

meshed door to

reach filter)

Fan retaining

screws (2 each)

Wire mesh

Filter
