13-2 Cabinet and equipment wiring and cabling
AccessNode 323-3001-210 Issue 1.0
Use Table 13-1 to navigate through this chapter to find the wiring and cabling
information for the cabinet and equipment.
Table 13-1
Cabinet and equipment wiring information
If you want to find general
wiring information
regarding
Or more detailed wiring
information regarding
Then
turn to
Grounding page 13-4
cabinet grounding page 13-4
equipment grounding page 13-6
AC power distribution page 13-7
ac load box page 13-8
ac power pedestal page 13-11
ac input to the rectifier page 13-15
DC power distribution page 13-16
rectifier dc output page 13-17
dc distribution shelf dc power page 13-18
dc distribution shelf circuit
breaker designations
page 13-19
battery breaker panel dc power
connections
page 13-22
battery breaker panel circuit
breaker designations
page 13-23
breaker interface panel wiring page 13-26
battery interface panel circuit
breaker designations
page 13-27
fan power wiring page 13-28
battery interface feed page 13-29
alarm wiring page 13-32
—continued—
