Connecting commercial power 3-3
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
AC power
The cabinet operates within specification with voltage range variations of 190
to 253 Vac (measured between Line 1 (L1) and Line 2 (L2) of the ac input
leads) and a frequency variation range of 55 to 65 Hz.
Table 3-1 shows the commercial ac power requirements for the S800A.
Cable entry
The S800A cabinet is constructed with cable conduit entry ports located at the
bottom of the end compartments of the cabinet.
Note: All trade sizes listed are based on Schedule 40 permanent virtual
circuit (PVC).
Load box option
For the load box option, there are two 2.50-inch openings for 2.00-inch trade
size conduit and a 1.50-inch opening for 1.00-inch trade size conduit.
The ac power enters the S800A cabinet via conduit holes located on the bottom
left side of the ac power compartment.
Table 3-2 shows the conduit openings in the ac load box.
Table 3-1
AC power requirements
Voltage Amperage Phase Frequency
AC load box option
115/230 Vac 60 A Three-wire, 1-phase 55-60 Hz
AC power pedestal option
115/230 Vac 100 A Three-wire, 1-phase 55-60 Hz
Table 3-2
AC load box conduit openings
Opening
size
Conduit
trade size Function
2.50 inches
(6.35 cm)
2.0 inches
(5.08 cm)
Miscellaneous - dc feed, when required
2.50 inches
(6.35 cm)
2.0 inches
(5.08 cm)
AC entrance - commercial ac feed
1.50 inches
(3.81 cm)
1.0 inches
(2.54 cm)
Ground - earth ground rod connection entrance
