13-32 Cabinet and equipment wiring and cabling
AccessNode 323-3001-210 Issue 1.0
Alarm wiring
Alarm wiring connects to the BIP pin field located on the front left of the BIP
faceplate from the equipment external to the AccessNode.
Equipment external to the AccessNode is alarmed through the BIP via the pin
field (see Table 13-7). Reference the specific shelf wiring and cabling section
in this chapter for more information regarding alarm wiring.
The alarms are provisioned via AccessNode software. Refer to NTP
323-3001-302, System Administration Procedures, in Operations,
Administration, and Provisioning, Volume 4A, for alarm provisioning
information.
Alarm cabling and wiring is also detailed in Table 13-10 on page 13-43.
Table 13-7
Alarm wiring for E2A external connections
Scan
point
Alarm
description
Alarm
severity Source
Source
connector and
pin number
BIP Pin
field pin
number
1 AC FA Minor DC distribution shelf 14 1
1 AC FA RET DC distribution shelf 15 2
2 LVA Major DC distribution shelf 3 3
3 REMOTE ACO N/A A/N 4
4 DOALM Minor Cabinet 7 6
5 LTEMP ALM Major Sensor 7
6 FA Major BBP/DC distribution shelf 5 9
7 PWR MN Minor DC distribution shelf 1 10
8 PWR MAJ Major DC distribution shelf 2 12
9 RPTR FA Minor RPTR 1, 2 Pos. 23, Pin 14 13
9 RPTR FA RET RPTR 1, 2 Pos. 23, Pin 16 14
10 RPTR LOS Minor RPTR 1, 2 Pos. 23, Pin 8 15
10 RPTR LOS RET RPTR 1, 2 Pos. 23, Pin 10 14
11 RPTR ERR Minor RPTR 1, 2 Pos. 23, Pin 2 16
11 RPTR ERR RET RPTR 1, 2 Pos. 23, Pin 4 17
LGND Alarm Reference All of the above Per Application 5, 8,
11, 18
