Nortel SONET AccessNode 800A Series User Manual

Installing the OSP cables 4-3
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Cable entry
The S800A cabinet is constructed with cable conduit entry ports located in the
bottom of the end compartments of the cabinet (see Figure 4-1 on page 4-7).
Note: All trade sizes listed are based on Schedule 40 permanent virtual
circuit (PVC).
In the termination compartment there are four 4.50-inch inside diameter (ID)
openings for 4.00-inch trade size conduit and on, 2.00-inch ID opening for
1.50-inch trade size conduit.
Table 4-1 shows the conduit openings in the termination compartment.
Table 4-1
Termination compartment conduit openings
Opening size Conduit trade size Function
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF - pairs 1–600 cable entrance
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF - pairs 601–1200 cable entrance
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF - miscellaneous cable entrance
4.50 inches
(11.43 cm)
4.00 inches
(10.16 cm)
VF - HF or fiber cable entrance
2.00 inches
(5.08 cm)
1.50 inches
(3.81 cm)
Earth ground rod connection entrance
