Nortel SONET AccessNode 800A Series - AC Power Pedestal

Cabinet and equipment wiring and cabling 13-11
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
AC power pedestal
The ac load box wiring diagrams and schematics detail the wiring and cabling
schematics for the NT7A68-- ac power pedestal options.
Table 13-2 on page 13-8 shows the circuit breaker designations and the lead
connections for the NT7A68-- power pedestal options (see Figure 13-6 on
page 13-13 and Figure 13-7 on page 13-14).
Note: Refer to Figure 13-2 on page 13-5 for the cabinet ac outlet box
wiring which is common to all of the ac distribution options
The NT7A68AA-CA 60/100 amp power pedestal has the 100 amp main
service entrance coupled with the 60A emergency service transfer switch for
powering from an externally located generator.
The NT7A68DA-FA 100/100 amp power pedestal has the 100 amp main
service entrance coupled with the 100 amp emergency service transfer switch
for powering from an externally located generator.
Figure 13-6 on page 13-13 shows the wiring of the NT7A68AA-CA 60/100
amp ac power pedestal options.
Figure 13-7 on page 13-14 shows the wiring of the NT7A68DA-FA 100/100
amp ac power pedestal options.
