Cabinet and equipment wiring and cabling 13-7
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
AC power distribution
AC power distribution within the S800A cabinet is provided through the
NT7A71AA-CA load box or the NT7A68AA-CA/DA-FA power pedestal
options. This section details the wiring diagrams and schematics for these ac
power options.
For cabinets and mechanical options, the suffixes denote paint color.
Figure 13-4 on page 13-9 shows the cabinet ac power distribution diagram for
cabinets equipped with the NT7A71AA-CA 100/100 amp load box options.
Figure 13-5 on page 13-10 shows the cabinet ac outlet box wiring diagram for
the S800A which is common to all of the ac power distribution options.
Figure 13-6 on page 13-13 shows the wiring of the NT7A68AA-CA 60/100
amp ac power pedestal options.
Figure 13-7 on page 13-14 shows the wiring of the NT7A68DA-FA 100/100
amp ac power pedestal options.
Suffix Color
AA/DA Brown
BA/EA Ivory
CA/FA Green
