Connecting commercial power 3-7
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 3-2
Wiring the ac load box as a branch circuit
Use this procedure to wire the ac load box option as a branch circuit. Wire only
the option specified by the job requirements.
Tools required
• voltmeter
• one medium flat blade screwdriver
• one small flat blade screwdriver
• one wire stripper for 6 AWG, 10 AWG and 12 AWG wire
Material required
• one 2-inch NPT knockout connector or equivalent
Precautions
The following safety precautions should be observed at all times during the
cabinet installation procedures:
• No equipment should be installed until the cabinet is firmly secured to its
mounting pad, as described in Chapter 2, “Installing the cabinet”.
• Do not open the front or rear doors unless the cabinet is firmly secured to
the mounting pad.
• Observe all NEC and local codes for electrical wiring.
—continued—
Load box wiring options Procedure
Branch circuit Procedure 3-2 on page 3-7
Main service entrance panel Procedure 3-3 on page 3-10
CAUTION 1
Electrical shock hazard
The procedures listed in this chart should be done by a
qualified electrician. The procedures outlined are
recommended guidelines; be sure to follow all local codes
for wiring procedures.
To Next Page
