Page #49 background imageLoading...
Page #49 background image
Installing the cabinet 2-5
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
AC power pedestal
For cabinets equipped with the optional attached ac power pedestal, there is a
3.5 in. ID opening for 2.5 in. trade size conduit for ac supply and four 2 in. ID
openings for 1.25 in. trade size conduit for miscellaneous cabling and
grounding as required (see Figure 2-3 on page 2-11).
Table 2-4 shows the conduit openings in the ac power pedestal.
Table 2-4
AC power pedestal conduit openings
Opening size Conduit trade size Function
3.50 in.
(8.89 cm)
2.50 in.
(6.35 cm)
AC entrance - commercial ac feed
2.00 in.
(5.08 cm)
1.25 in.
(3.18 cm)
Miscellaneous - dc feed or grounding
2.00 in.
(5.08 cm)
1.25 in.
(3.18 cm)
Miscellaneous - dc feed or grounding
2.00 in.
(5.08 cm)
1.25 in.
(3.18 cm)
Miscellaneous - dc feed or grounding
2.00 in.
(5.08 cm)
1.25 in.
(3.18 cm)
Miscellaneous - dc feed or grounding
