2-4 Installing the cabinet
AccessNode 323-3001-210 Issue 1.0
Table 2-2 shows the conduit openings in the termination compartment.
AC load box option
The ac load box option has two 3 in. ID openings for 2 in. trade size conduit
and a 1 in. ID opening for 1 in. trade size conduit for grounding.
The ac power enters the S800A cabinet via conduit holes located on the bottom
left side of the ac power compartment.
Table 2-3 shows the conduit openings in the ac load box.
Table 2-2
Termination compartment conduit openings
Opening size Conduit trade size Function
4.50 in.
(11.43 cm)
4.00 in.in.
(10.16 cm)
VF - pairs 1–600 cable entrance
4.50 in.
(11.43 cm)
4.00 in.
(10.16 cm)
VF - pairs 601–1200 cable entrance
4.50 in.
(11.43 cm)
4.00 in.
(10.16 cm)
VF - miscellaneous cable entrance
4.50 in.
(11.43 cm)
4.00 in.
(10.16 cm)
VF - HF or fiber cable entrance
2.00 in.
(5.08 cm)
1.50 in.
(3.81 cm)
Earth ground rod connection entrance
Table 2-3
AC load box conduit openings
Opening size Conduit trade size Function
3.0 in.
(7.62 cm)
2.0 in.
(5.08 cm)
Miscellaneous - dc feed, when required
3.0 in.
(7.62 cm)
2.0 in.
(5.08 cm)
AC entrance - commercial ac feed
1.5 in.
(3.81 cm)
1.0 in.
(2.54 cm)
Earth ground rod connection entrance
