Installing and connecting the batteries 9-27
AccessNode Series 800A Outside Plant Cabinet Installation 323-3001-210 Issue 1.0
Procedure 9-3 (continued)
Wiring the cabinet when the batteries are installed in the battery vault
Figure 9-13
Battery cable routing from the vault to the cabinet
FW-15036
—continued—
Batt 1
-48v
RED
Batt 2
-48v
RED
Batt 1
BR
BLK
Batt 2
BR
BLK
DC shf
-48V
Batt 3
RED
DC shf
-48V
Batt4
RED
DC shf
BR
Batt 3
BLK
DC shf
BR
Batt 4
BLK
FW-15036
Battery vault
cabling connections
(TB13) (Provided in cabinet)
Battery cabling
Vault
