2-6 Installing the cabinet
AccessNode 323-3001-210 Issue 1.0
Figure 2-1
Trade size conduit usage and placement
FW-15100
0.00
5.85 in.
12.62 in.
19.39 in.
22.78 in.
26.16 in.
14.86 cm
32.05 cm
49.25 cm
57.86 cm
66.44 cm
0.00
2.71 in. 5.04 in.
6.88 cm.
12.80 cm.
170.33 cm
185.44 cm 186.11 cm 182.88 cm 203.20 cm
67.06 in.
73.01 in. 73.27 in. 72.00 in.
80.00 in.
10.50 in
12.00 in
14.50 in
18.50 in
20.65 in
21.88 in
24.90 in
27.88 in
32.00 in
26.67 cm
30.48 cm
36.83 cm
46.99 cm
52.45 cm
55.58 cm
63.25 cm
70.82 cm
81.28 cm
0.00
Edge of raised
section of pad
Conduit size table
(All conduits: schedule 40 PVC)
A
B
C
D
E
1.00 in.
1.25 in.
2.00 in.
2.50 in.
4.00 in.
2.54 cm
3.18 cm
5.08 cm
6.35 cm
10.16 cm
Conduit Trade size
1.50 in.
2.00 in.
3.00 in.
3.50 in.
4.50 in.
3.81 cm
5.08 cm
7.62 cm
8.89 cm
11.43 cm
Opening
FW-15100
Edge of raised
section of pad
VF (1-600)
E
VF (601-1200)
E
VF (Misc.)
E
HF or fiber
E
Ground (Where required by local code)
B
Ground
(AC service)
A
AC entrance
C
Misc.
Misc.
AC entrance
D
Misc.
B
Misc.
B
C
Miscellaneous
(DC feed, when
required)
B
B
