6-24 Routing and terminating the VF cables
AccessNode 323-3001-210 Issue 1.0
Procedure 6-5 (continued)
Connecting the VF cable pairs 601–1200 to 710 or 3M MS2 DPM connectors with cross-connect
Special tools required
For 710 connectors, use the Western Electric 945A Splicing Tool Kit. For 3M
connectors, use the 4045K Universal Splicing Rig (or equivalent splicing kit
for 3M MS
2
connectors).
Support bars and binder groups
Table 6-2 (pair count top to bottom) outlines each binder group and its
respective swing frame support bar position.
—continued—
Table 6-2
Routing binder groups across the swing frame (pair count top to bottom)
Support
bar
VF line
number
Column 1
binder group
Distribution
Pairs 601
–1200
Column 2
SPC cables
Feeder
Pairs 1
–600
Column 3
binder group
Distribution
Pairs 1
–600
1 1–25 White / Blue 1–25 White / Blue
1 26–50 White / Orange 26–50 White / Orange
2 51–75 White / Green 51–75 White / Green
2 76–96 White / Brown 76–100 White / Brown
3 97–121 White / Slate 101–125 White / Slate
3 122–146 Red / Blue 126–150 Red / Blue
4 147–171 Red / Orange 151–175 Red / Orange
4 172–192 Red / Green 176–200 Red / Green
5 193–217 Red / Brown 201–225 Red / Brown
5 218–242 Red / Slate 226–250 Red / Slate
6 243–267 Black / Blue 251–275 Black / Blue
6 368–288 Black / Orange 276–300 Black / Orange
7 289–313 Black / Green 301–325 Black / Green
7 314–338 Black / Brown 326–350 Black / Brown
8 339–363 Black / Slate 351–375 Black / Slate
8 364–384 Yellow / Blue 376–400 Yellow / Blue
9 385–409 Yellow / Orange 401–425 Yellow / Orange
9 410–434 Yellow / Green 426–450 Yellow / Green
10 435–459 Yellow / Brown 451–475 Yellow / Brown
10 460–480 Yellow / Slate 476–500 Yellow / Slate
11 481–505 Violet / Blue 501–525 Violet / Blue
11 506–530 Violet / Orange 526–550 Violet / Orange
12 531–555 Violet / Green 551–575 Violet / Green
12 556–576 Violet / Brown 576–600 Violet / Brown
